-40%
Discover D1272 12V 7.2Ah VRLA AGM Float Standby SLA Battery F1 Terminal
Original price was: $41.90.$25.14Current price is: $25.14.
In stock
MECHANICAL SPECIFICATIONS
| Industry Reference | ||
| Length A (in/mm) | 5.9 | 151 |
| Width B (in/mm) | 2.6 | 65 |
| Height C (in/mm) | 3.7 | 95 |
| Total Height D (in/mm) | 4 | 101 |
| Weight (lbs/kgs) | 4.73 | 2.15 |
| Terminal * | F2 | |
| Technology | AGM, VRLA | |
NOTE 1: Dimensions have a ±2 mm (0.08 in) tolerance. Weights may vary.
NOTE 2: Refer to terminal guide on website for torque values.
ELECTRICAL SPECIFICATIONS
| Voltage (V) | 12 | |
| Internal Resistance (mΩ) | 35 | |
| Short Circuit (A) (20°C / 68°F) | 300 | |
| Self-Discharge (20°C / 68°F) | 2-3% per month | |
| Charge Temperature | Min: -10°C (14°F) | Max: 50°C (122°F) | |
| Discharge Temperature | Min: -40°C (-40°F) | Max: 50°C (122°F) | |
| Storage Temperature | -20°C (-4°F) to 60°C (140°F) | |
NOTE 3: Extra considerations must be given when designing systems for use at maximum temperatures.
NOTE 4: Internal Resistance is approximate.
PERFORMANCE SPECIFICATIONS
| Amp Hours (AH) | |||
|---|---|---|---|
| 1 HR | 5 HR | 10 HR | 20 HR |
| 4.5 | 6.2 | 6.8 | 7.2 |
1HR @1.60VPC, 5HR @1.75VPC; 10 HR@ 1.80VPC; 20 HR @1.80VPC. All at 30°C/86°F
| Discharge Constant Current (Amperes) @ 25°C / 77°F | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| VPC/Time | 5 MIN | 10 MIN | 15 MIN | 30 MIN | 1 HR | 3 HR | 5 HR | 10 HR | 20 HR |
| 1.60 VPC | 29.40 | 18.40 | 14.80 | 8.30 | 4.56 | 1.91 | 1.30 | 0.72 | 0.38 |
| 1.65 VPC | 27.50 | 17.50 | 14.20 | 7.90 | 4.40 | 1.86 | 1.28 | 0.71 | 0.38 |
| 1.70 VPC | 26.00 | 16.70 | 13.60 | 7.62 | 4.22 | 1.80 | 1.26 | 0.71 | 0.37 |
| 1.75 VPC | 24.40 | 15.70 | 13.00 | 7.24 | 4.04 | 1.73 | 1.24 | 0.70 | 0.37 |
| 1.80 VPC | 22.80 | 14.80 | 12.40 | 7.03 | 3.84 | 1.67 | 1.21 | 0.68 | 0.36 |
| Discharge Constant Power (Watts) @ 25°C / 77°F | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| VPC/Time | 5 MIN | 10 MIN | 15 MIN | 30 MIN | 1 HR | 3 HR | 5 HR | 10 HR | 20 HR |
| 1.60 VPC | 52.50 | 35.30 | 28.50 | 158.00 | 9.30 | 3.68 | 2.38 | ||
| 1.65 VPC | 49.60 | 33.50 | 27.20 | 15.20 | 8.90 | 3.56 | 2.34 | ||
| 1.70 VPC | 46.70 | 31.80 | 25.80 | 14.50 | 8.52 | 3.49 | 2.30 | ||
| 1.75 VPC | 43.50 | 29.60 | 24.60 | 13.80 | 8.13 | 3.38 | 2.25 | ||
| 1.80 VPC | 40.20 | 27.50 | 23.20 | 13.20 | 7.75 | 3.27 | 2.19 |
| Weight | 10.43 lbs |
|---|---|
| Dimensions | 5.94 × 2.56 × 3.74 in |
| Voltage | 12 Volts |
| Rating | 12V 7.2Ah |
| Warranty | 12months warranty against manufacturers defects |
| Brand |
